YYQW Series Industrial Gas Diesel Oil Fired Thermal Oil Heater
Boiler
Special features of thermal oil heater boiler
1. Professional industrialized packing design,stainless steel
packing
harmonious structure proportion,nice appearance,real steel material
2. Unique tail heating surface design,boiler rolling chamber wet
back structure,small boiler heat loss,avoid overheat caused by
over-burning of side panels, and increase thermal efficiency by
2-3%
3. Integrated and wiring device,more convenience for the wire
connection,make overhaul more simply,elegant appearance after
installation
4. double-deck aluminum silicate for heat preservation,the surface
temperature of the boiler is no higher than 40℃,energy conservation
and efficient
5. The outer oil collecting box is designed to prevent the slow
rate of grease from carbonizing avoid air leakage
6. Double seal groove design, secondary prevent air leakage design,
tight seal, avoid air leakage
7. Research PCL control board independently,strong
compatibility,PLC intelligent touch screen equipment,10-inch touch
screen,fool-type operation,safe and reliable,automatic
ignition/flame-out/fire switch,high fired gas,low pressure
protection,gas leakage protection
Technical parameter table of thermal oil heater boiler for
reference
| Item | Unit | Data |
| Rated capacity | KW(kcal) | 1400KW(1200,000kcal) |
| Design pressure | Mpa | 0.8Mpa |
| Hydrostatictest | Mpa | 1.2 |
| Rated output temperature | °C | 280 |
| Rated return temperature | °C | 250 |
| Heat carrier circulation flow capacity | m³/h | 74.696 |
| Heating area | Radiative heating area | ㎡ | 7.797 |
| Convection tube heating area | ㎡ | 45.29 |
| Heating area of economizer | ㎡ | 25.749 |
| Design efficiency(heavy oil fired) | % | 92.65 |
| Exhaust temperature(heavy oil fired) | °C | 123.56 |
| Fuel consumption (heavy oil fired) | kg/h | 131.8 |
| Heat carrier medium capacity in furnace | m³ | 1.2 |
| Medium flow speed in radiation area | m/s | 2.54 |
| Medium flow speed in convection area | m/s | 2.54 |
| Weight | Ton | 4 |
| Dimension | mm | 3710*1524*2150 |
Thermal Oil Boiler System application
1. Widely used in petroleum, chemical, pharmaceutical, textile
printing and dyeing, light industry, building materials, food, road
asphalt heating and other industrial fields requiring high
temperatures.
2. Our customers bought thermal oil heater boiler, generally for
plywood production process, bitumen making, plate material
processing.
Thermo Oil Boiler running advantages
(1) High effiency and energy saving.
(2) High temperature oil output.
(3) Safe and reliable.
(4) Long life span (More than 20 years ).
(5) Intelligent and fully automatic.
(6) Easy inspection and maintenance.
Thermal Oil Heater Boiler Delievery
1.The boiler main unit and the large auxiliary equipment are naked,
and other precision instruments or small auxiliary equipment are
packed in wooden boxes.
2.According to the tonnage of the boiler,we use 20-foot
cabinet,40-foot cabinet,20 frame or 40 frame box for shipment.
3. All goods will be professionally reinforced after being loaded
into the container.
4. We have a stable and cooperative freight company that can ensure
the safety of the goods and ensure low transportation costs.
