Packaged 2 To 8 Ton / Hour Rice Husk Steam Boiler In Sugar Factory
SZL industrial low pressure horizontal double drums water tube
automatic chain grate stoker boilers are with the structure of
double drums, horizontal, water tube, automatic chain grate, water
cooling arch, cyclone combustion chamber. The higher combustion
space formed by two drums are good for the combustion of fuels, and
the cyclone combustion chamber are good for fuel to burn out,
increasing boiler efficiency greatly.
The characteristics and advanatges of SZL industrial low pressure
horizontal double drums water tube automatic chain grate stoker
boilers include,
1. Double drums
2. Water drum
3. Water cooling arch
4. Cyclone combustion chamer
5. Automatic moving chain grate stoker
6. SZL water tube boilers biomass fuel rice husk wood chips fired
for sale
| Model | Rated capacity | Rated pressure | Feed water temp | Rated steam temp | Boiler efficiency | Weight | Dimension | Delivery Mode |
| t/h | Mpa | ℃ | ℃ | % | Ton | mm |
| SZH2-1.25/2.5-AII | 2 | 1.25/2.5 | 20 | 194/226 | 81 | 17/18.5 | 4850×2690×3468 | Package Bolier |
| SZH4-1.25/2.5-AII | 4 | 1.25/2.5 | 20 | 194/226 | 81 | 22/24.8 | 5450×3040×3468 |
| SZL2-1.25/2.5-AII | 2 | 1.25/2.5 | 20 | 194/226 | 81.6 | 20/25 | 5960×2960×3468 |
| SZL4-1.25/2.5-AII | 4 | 1.25/2.5 | 20 | 194/226 | 81.6 | 28/29 | 6510×3130×3468 |
| SZL6-1.25/2.5-AII | 6 | 1.25/2.5 | 20 | 194/226 | 81.6 | 38/42 | 7830×3346×3468 |
| SZL8-1.25/2.5-AII | 8 | 1.25/2.5 | 20 | 194/226 | 81.8 | 52 | 8200×3346×3468 |
| SZL10-1.25/2.5-AII | 10 | 1.25/2.5 | 20 | 194/226 | 82 | 68 | 8500×3346×3482 | Assembled Boiler |
| SZL15-1.25/2.5-AII | 15 | 1.25/2.5 | 20 | 194/226 | 82.3 | 30 | 9583×3400×3550 |
| SZL20-1.25/2.5-AII | 20 | 1.25/2.5 | 20 | 194/226 | 82.3 | 40 | 11600×3460×3520 |
Our service
In order to optimize the user experience of Yuanda boiler, in the
service process,Yuanda boiler has always been user-oriented,
specifically described as follows:
1. Time is everything, once the user service requirements, we will
immediately deal with Secretary;
2. Service technical staff has a strong professional knowledge and
excellent technical ability, strong operational capacity;
3. Consider the needs of users as the most important all times.
FAQ
Q: Your company is a transactional company or an industrial
manufacture factory?
A: We are an industrial manufacture factory which locates in
Zhoukou city.And we hava sales center in Zhengzhou.
Q:All of your products are made by your self or compacted via
purchasing the others?
A: We have independent technical team who focus on making machines,
all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications
for our clients, also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients
should be satisfied first.
Welcome customer come to visit our factory !
