Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry

    Buy cheap Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry from wholesalers

    Buy cheap Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry from wholesalers
    • Buy cheap Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry from wholesalers

    Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry

    Ask Lasest Price
    Brand Name : Yuanda Boiler Corporation
    Model Number : LHS,LSS
    Certification : ISO CE SGS ASEM
    Price : Can be discussed.
    Payment Terms : D/P, D/A, L/C, Western Union, T/T
    Supply Ability : 600 sets per year
    Delivery Time : 25 days after payment
    • Product Details
    • Company Profile

    Diesel Fired Vertical Water Tube Boiler Capacity 350Kw For Laundry

    Diesel Fired Vertical Steam Boiler Capacity 350Kw For Laundry


    This series boiler adopts vertical through flow and three-pass furnace. The burner is down-fired type.The flame can completely spread from the top down to make burning full. The gas need to make a three-pass heat transfer, so the heat loss will be reduced and the thermal efficiency will be higher.



    Features of vertical steam boiler


    1. Crossflow struture, advanced level at domestic and international;
    2. After 4 to 5 minutes ignition, it can get enough pressured steam;
    3. Automatically control combustion, steam pressure and water level; ensure safe and economical operation;
    4. Combustiong gas flowing among conduit group at a high speed that assures high quality heat convection and transfer and high effect heat absorption;
    5. Quiet operation and stable combustion, compeletely according with environmental protection standard;
    6. Perfect boiler body structure ensures high quality heating absorption and high combustion efficiency up to 92%-96%;
    7. High technology, high quality,fully automatic CO2 welding;Parts standardization and quality assurance.


    ModelRated evaporation capacity (t/h)Working pressure (Mpa)Heating Area (m2)Thermal efficiency (%)Overall dimension (m)Weight (t)
    LSS0.1-0.4-Y(Q)0.10.43890.8x 1.940.83
    LSS0.2-0.4-Y(Q)0.20.4389.20.9x 2.71
    LSS0.3-0.4/0.7-Y(Q)0.30.4/0.7389.51.2x 2.581.28
    LSS0.5-0.4/0.7-Y(Q)0.50.4/0.7389.61.3x 2.952.1
    LSS0.7-0.4/0.7-Y(Q)0.70.4/0.73911.6x 3.03.5
    LSS1-0.4/0.7-Y(Q)10.4/0.73911.5x 3.24.1

    Note: Parameter is for reference only, if any changes should follow the factory technical data.

    Customer Visit


    Yuanda boiler brand has a certain popularity in China mainland,we have made great progress in domestic market and part foreign countries.According to statistics,by the end of 2017, the products of Yuanda Boiler have exported to more than 80 countries in the world.Take some moments in pictures as following:



    Boiler application


    Medicine, chemical, light industry, textile, building material, cultivation, food and beverage, plastic foam, printing, dyeing and washing, rubber processing, paper products,wood processing, hotel, clothing and leather manufacturer etc.


    Yuanda Boiler Mainly Products


    Water tube boiler: Steam and water flows in tube, the water quality requirements are high.
    Fire tube boiler: Flue gas flows in fire tube. Generally small-capacity boilers, there is low water quality requirements.
    Water-fired boiler: At the boiler heating surface,there are some pipe which inside are flue gas,some pipes inside are water.


    Our product series includes more than 150 kinds. The main products are:
    (1) DZL coal fired steam boiler/hot water boiler(1-20ton/h;0.7-14MW)
    (2) DZH wood fired steam boiler/hot water boiler(1-6ton/h;0.7-4.2MW)
    (3) SZL biomass/solid fired steam boiler/hot water boiler (1-20ton/h;0.7-14MW)
    (4) WNS series gas/oil fired steam boiler(0.5-20ton/h;0.35-14MW)
    (5) WNS series gas condensing boiler(1-10ton/h)
    (6) YY(Q)W gas /oil fired thermal oil boiler(100,000kcal-12,000,000kcal)
