6 T / Hr Wood Fired Steam Boiler Coal Burning Continous Heating
Output
The DZL/DZH new water-fire tube boiler is a new eco-friendly and
energy-saving product co-developed by our company and famous Harbin
institute of Technology and director of Beijing Institute of Light
Boiler.
1. Boiler model:DZL/DZH
2. Boiler capacity:1-20ton/h
3.
Pressure:1.0Mpa(10bar),1.25Mpa(13bar),1.6Mpa(16bar),2.5Mpa(25bar)
4. Steam temperature:184 °c,194°c, 204°c,226°c(As long as below
226°c,we can do it)
5. Fuel:coal,biomass
6. Structure:horizontal water-fire tube, single drum
7. Type:There are two types.One is DZL chain grate stoker automatic
feeding fuel and removing dregs type. Another is DZH hand operated
moving grate type which needs labour to feed fuel and remove the
dregs.
8.Application:Medicine, chemical, light industry, textile, building
material, cultivation, food and beverage, plastic foam, printing,
dyeing and washing, rubber processing, paper products,wood
processing, hotel, clothing and leather manufacturer etc.
Advanatages of steam boiler
1. The output power remain constant
2. The boiler is heating up quickly and have high heat efficiency
3. Low original dust concentration,environmental protection and
energy conservation
4. High quality of steam
5. Strong water quality adaptability
6. Small size appearance, low investment in boiler room
7. Low running cost, safe and reliable (safety and reliability)
8. Short installation time, low installation cost
Accessories of boiler equipment
| Product name | Quantity (set) |
| Boiler Main Part | 1 |
| Draft Fan | 1 |
| Forced Fan | 1 |
| Electric Controller | 1 |
| Valve | 1 |
| Pressure Gauge | 1 |
| Water Pump | 2 |
| Smoke Chimney | 1 |
| Smoke Ducting | 1 |
| Economizer | 1 |
| Ceramic-Cyclone | 1 |
| Water Treatment Equipment | 1 |
| Electrical cabinet | Be responsible for electrical control of auxiliary machines, ensure
the whole system work automatically and make operation convenient. |
| Feed water pump & water circulating pump | Put water into boiler and promote hot water circulation.Compact
structure,low power consumption,low failure rate |
| Automatic water softener | Remove Mg+,Ca+ in the water and improve water quality. Prevent hurt
to boiler tube,entend the boiler using life time. |
| Economizer | Heat inlet water and reduce exhausted gas temperature, which
increase boiler efficiency and is good for environment |
| Steam header | Distribute steam to different directions.Used for distributing the
steam to each pipe of user's workshop |
| Forced draught fan | Blow clean air into the boiler and promote exhauted gas out, ensure
the air circulation of the whole system. |
| Dust collector | Remove the dust and ash in exhausted gas to protect envrionment and
reduce polutions. |
| Gas flue and Chimney | Provide channels for exhausted gas flow. |
| Fuel feeding | Automatic feeding device |
| Grate speed adjustor | Regulate the suitable speed of chian grate according to the
combustion situation. |
| Slag remover | Extract slags mechanically and save labour cost. |
| Induced draught fan | Blow clean air into the boiler and promote exhauted gas out, ensure
the air circulation of the whole system. |
| Safety Valves | It will work automatically when the working pressure is over high
to protect the whole system |
| Pressure Gauge | Show the working pressure of the boiler |
| Check Valves | Connect pipes to ensure water not to flow backwards |
| Blow-down Valves | To let out the sediment, impurities or other things in the bottom |
| Shut-off Valves | Turn on or off the pipes |
Our service
1. Consultation service: Experienced technicians guidance is
available on the phone, and on the internet.
Installation service: One or more engineers will be dispatched to
the installation site to help install the customers’ boilers.
2. Training service: We also provide necessary training about
boiler operation and daily maintenance to local workers.
3. Warm service: Based on customers’ request and budget, our
experts make efficient, reliable solutions, and we produce strictly
following customers’ order. Every customer has the chance to visit
our workshops before placing the order.
