Diesel Boiler Fire Tube Steam Boiler 10Ton Heavy Oil Fired Boiler
Special design features of boiler
1. Adopt domestic and foreign advanced large furnace design
Increase the diametre of furnace on the basis of original
traditional design.expand the surface of radiant heat
exchange,mainly center on radiant heat exchange ,reduce the heat
exchange burden during the second and third return,and make the
fuel burning efficiently,reduce the harmful gas production.
Besides,the spiral hearth in the high temperature area not only
increase the area of radiant heat exchange, but also make a
resistance to the smoke movement.have a obvious effect about
radiation heat exchange.
2. Research PCL control board independently
Strontg conpatibility,PLC intelligent touch screen equipmet,10-inch
touch screen,fool-type operation,safe and reliable,automatic
ignition/flame-out/fire switch,high fired gas,low pressure
protection,gas leakage protection,filling and stopping pump
automatically,high and low water warning,ultra low water-level
interlock,alarm when the temperature of smoke exhaust is too high
and stop furnace operating.
3. Large load imported burner configuration
80% configuration ratio,light load drive,enough thermal energy
import,guaranteed output,reduce equipment use fatigue,extend the
service life,the quality of inlet valve group is steady and
reliable.
Technique parameter of gas fired steam boiler
| Boiler model | Rated capacity | Rated pressure | Rated Feed temp. | Rated Steam temp. | Fuel consumption | Thermal efficiency | Dimensions |
| Natural gas | Liquid gas | City gas |
| t/h | Mpa | ℃ | ℃ | m3/h | m3/h | m3/h | % | mm |
| WNS1-1.0-Y(Q) | 1 | 1 | 20 | 184 | 84.2 | 29 | 176 | 91 | 3561×1690×1910 |
| WNS 2-1.25- Y(Q) | 2 | 1.25 | 20 | 194 | 165 | 57.3 | 346 | 92 | 4111×1950×2199 |
| WNS3-1.25-Y(Q) | 3 | 1.25 | 20 | 194 | 250 | 82 | 510 | 92.1 | 4330×2248×2564 |
| WNS4-1.25- Y(Q) | 4 | 1.25 | 20 | 194 | 323.6 | 109 | 682 | 93 | 4732×2150×2448 |
| WNS5-1.25- Y(Q) | 5 | 1.25 | 20 | 194 | 386 | 140 | 87 | 93 | 5970×2360×2796 |
| WNS6-1.25- Y(Q) | 6 | 1.25 | 20 | 194 | 450 | 164 | 1020 | 93.2 | 5500×2600×2990 |
| WNS8-1.25- Y(Q) | 8 | 1.25 | 105 | 194 | 642 | 209 | 1321 | 93.5 | 6450×2800×3200 |
| WNS10-1.25- Y(Q) | 10 | 1.25 | 105 | 194 | 805 | 264 | 1654 | 93.5 | 6800×2900×3394 |
| WNS15-1.25- Y(Q) | 15 | 1.25 | 105 | 194 | 1182 | 400 | 2417 | 93.5 | 7150×3200×3540 |
| WNS20-1.25- Y(Q) | 20 | 1.25 | 105 | 194 | 1597 | 520 | 3299 | 93.5 | 8200×3400×3826 |
Steam boiler running advantages
1. High heating efficiency and good steam quality.
2. Long boiler using life, more than 25 years.
3. Beautiful boiler apperance and convenient boiler design.
4. Boiler fuel consumption less than others, energy saving boiler.
5. Adopt newest heat transfer technology, superior boiler structure
design.
Steam boiler application
1. Agriculture
2. Animal food industry
3. Automotive industry
4. Bakeries
5. Ceramic industry
6. Cheese dairies
7. Chemical industry
8. Dairies
9. Distilleries
10. Dyeing factories
11. Electrical industry
12. Food packaging industry
13. Fruit processing
14. Glass fibre production
15. Greenhouses
16. Hospitals
17. Metal-working industry
18. Paper industry
19. Pharmaceutical industry
20. Plastics manufacturing
21. Primary industry
22. Print offices
23. Refineries
24. Slaughterhouses
25. Spinning mills
26. Steel works
27. Tank farms
28. Tobacco industry
29. Tyre manufacturing
30. Vulcanisation
31. Waste disposal
32. Waste incineration
33. Weaving mills
34. Wood processing
35. Wood products
