High Efficiency WNS Gas Powered Biogas Fire Tube Steam Boiler for
Central Heating
Introduction of WNS fire tube steam boiler
WNS series fire tube steam boiler is horizontal three pass fire
tube wet back full automatic steam boiler. It normally suitable for
500kg to 20ton/h capacity, use all kinds of gas and oil fuels,such
as natural gas, lpg,lng,cng,city gas,biogas, diesel oil,heavy oil.
1. Model:WNS
2. Capacity:500kg/h-20ton/h
3. Design pressure:1.0Mpa(10bar), 1.25Mpa(13bar),
1.6Mpa(16bar),2.5Mpa(25bar)
4. Stem temperature:below 224 degree
5. Design fuel:natural gas, lpg,lng,cng,city gas,biogas, diesel
oil,heavy oil
6. Structure: three pass fire tube wet back
Technical parameter of fire tube steam boiler
| Boiler model | Rated capacity | Rated pressure | Rated Feed temp. | Rated Steam temp. | Fuel consumption | Thermal efficiency |
| Light oil | Heavy oil | Natural gas | City gas |
| t/h | Mpa | ℃ | ℃ | kg/h | kg/h | m3/h | m3/h | % |
| WNS1-1.0-Y(Q) | 1 | 1 | 20 | 184 | 65.5 | 67.3 | 84.2 | 176 | 91 |
| WNS 2-1.25- Y(Q) | 2 | 1.25 | 20 | 194 | 129.6 | 132.2 | 165 | 346 | 92 |
| WNS3-1.25-Y(Q) | 3 | 1.25 | 20 | 194 | 192 | 195 | 250 | 510 | 92.1 |
| WNS4-1.25- Y(Q) | 4 | 1.25 | 20 | 194 | 256 | 261.9 | 323.6 | 682 | 93 |
| WNS5-1.25- Y(Q) | 5 | 1.25 | 20 | 194 | 318 | 322 | 386 | 87 | 93 |
| WNS6-1.25- Y(Q) | 6 | 1.25 | 20 | 194 | 380 | 390.6 | 450 | 1020 | 93.2 |
| WNS8-1.25- Y(Q) | 8 | 1.25 | 105 | 194 | 503 | 517 | 642 | 1321 | 93.5 |
| WNS10-1.25- Y(Q) | 10 | 1.25 | 105 | 194 | 628 | 643 | 805 | 1654 | 93.5 |
| WNS15-1.25- Y(Q) | 15 | 1.25 | 105 | 194 | 940 | 965 | 1182 | 2417 | 93.5 |
| WNS20-1.25- Y(Q) | 20 | 1.25 | 105 | 194 | 1250 | 1301 | 1597 | 3299 | 93.5 |
Fire tube steam boiler application fields
Medicine, chemical, light industry, textile, building material,
cultivation, food and beverage, plastic foam, printing, dyeing and
washing, rubber processing, paper products,wood processing, hotel,
clothing and leather manufacturer etc.
Fire tube steam boiler running advantages
1. Convenient and clean working
2. Low cost and high thermal efficiency
3. Long service life and simple maintenance
4. Easy installation and easy operation work
5. Fast and pure steam production in short minutes
6. Environmental friendly and long using life span
7. Simple boiler structure design and easy maintenance
