15Ton Steam Per Hour Diesel Oil Fired Steam Boiler For Brewery
Industry
General Introduction
WNS series gas/oil fired boiler used new type refractory material,
without pre load, heat efficiency, stable air pressure, and the
steam in a short period of time can produce high quality. When
burning, low noise, no pollution, flue gas, complete combustion, so
that it could save fuel costs and improve the economy efficiency.
This is a kind of product which is environmental protection and
energy saving.
1. The series boiler is three-return fire tube steam boiler.
2. It equipped with a bias furnace tube structure, and high
temperature gas into the
3. Atmosphere through three-return smoke tube, smoke chamber.
4. It equipped with good performance burner and advanced
techniques.
5. The burning control, water feed, programs run, etc. are full
automatic.
6. This boiler is safe and reliable, and also has the advantage of
compact structure,
7. Simple operation, easy installation, high efficiency, less
pollution and noise, etc.
8. It is widely used for factory, hotel, hospital, office building,
etc
Technical parameter
| Boiler model | Rated capacity | Rated pressure | Rated Feed temp. | Rated Steam temp. | Fuel consumption | Thermal efficiency | Weight | Dimensions |
| Light oil |
| t/h | Mpa | ℃ | ℃ | kg/h | % | ton | mm |
| WNS1-1.0-Y(Q) | 1 | 1 | 20 | 184 | 65.5 | 91 | 4.3 | 3561×1690×1910 |
| WNS 2-1.25- Y(Q) | 2 | 1.25 | 20 | 194 | 129.6 | 92 | 7.2 | 4111×1950×2199 |
| WNS3-1.25-Y(Q) | 3 | 1.25 | 20 | 194 | 192 | 92.1 | 8 | 4330×2248×2564 |
| WNS4-1.25- Y(Q) | 4 | 1.25 | 20 | 194 | 256 | 93 | 9.6 | 4732×2150×2448 |
| WNS5-1.25- Y(Q) | 5 | 1.25 | 20 | 194 | 318 | 93 | 12.5 | 5970×2360×2796 |
| WNS6-1.25- Y(Q) | 6 | 1.25 | 20 | 194 | 380 | 93.2 | 16.5 | 5500×2600×2990 |
| WNS8-1.25- Y(Q) | 8 | 1.25 | 105 | 194 | 503 | 93.5 | 24.8 | 6450×2800×3200 |
| WNS10-1.25- Y(Q) | 10 | 1.25 | 105 | 194 | 628 | 93.5 | 26.8 | 6800×2900×3394 |
| WNS15-1.25- Y(Q) | 15 | 1.25 | 105 | 194 | 940 | 93.5 | 38 | 7150×3200×3540 |
| WNS20-1.25- Y(Q) | 20 | 1.25 | 105 | 194 | 1250 | 93.5 | 55 | 8200×3400×3826 |
Accessories and Functions
| Descriptions | Functions |
| Burner | Ignition and make the fuel burning. |
| Water pump | Put water into boiler and promote hot water circulation.Compact
structure,low power consumption,low failure rate |
| Water softener | Remove Mg+,Ca+ in the water and improve water quality. Prevent hurt
to boiler tube,entend the boiler using life time. |
| PLC Touch screen control | Burner auto ignition,fire off,fire switch;Gas high and low pressure
protection; Gas leakage protection;Automatic feeding water and stop
the pump. |
| Electrical cabinet | Be responsible for electrical control of auxiliary machines, ensure
the whole system work automatically and make operation convenient. |
| Economizer | Heat inlet water and reduce exhausted gas temperature, which
increase boiler efficiency and is good for environment. |
| Gas flue and Chimney | Provide channels for exhausted gas flow. |
| Steam header | Distribute steam to different directions.Used for distributing the
steam to each pipe of user's workshop. |
| Safety Valves | It will work automatically when the working pressure is over high
to protect the whole system |
| Pressure Gauge | Show the working pressure of the boiler |
| Check Valves | Connect pipes to ensure water not to flow backwards |
| Blow-down Valves | To let out the sediment, impurities or other things in the bottom |
| Shut-off Valves | Turn on or off the pipes |
Advantages of horizontal gas/oil fired steam boiler
1. High heating efficiency and good steam quality.
2. Long boiler using life, more than 25 years.
3. Beautiful boiler apperance and convenient boiler design.
4. Boiler fuel consumption less than others, energy saving boiler.
5. Adopt newest heat transfer technology, superior boiler structure
design.
Transportation & Delivery
Packaging: Nude packaging for boiler main part and wood box
packaging for boiler accessories.
Shipping: Normally we use 20 container, 40container or 20 flat rack
container and 40 flat rack container to load it.Shipping way is
different according to customer's country. Mostly by sea,Some by
train.In order to ensure the customer get the product smoothly and
safely,our company has cooperated with professional transportation
team for the handing the land loading transport.
