10Ton Industrial Coal Fired Steam Boiler Moving Grate In Rice Mill
General initroduction
The DZL new water-fire tube boiler is a new eco-friendly and
energy-saving product co-developed by our company and famous Harbin
institute of Technology and director of Beijing Institute of Light
Boiler.
1. Boiler capacity:1-20ton/h
2.
Pressure:1.0Mpa(10bar),1.25Mpa(13bar),1.6Mpa(16bar),2.5Mpa(25bar)
3. Steam temperature:184 °c,194°c, 204°c,226°c(As long as below
226°c,we can do it)
4. Fuel: coal,biomass
5. Structure: horizontal water-fire tube, single drum
Application fields
Medicine, chemical, light industry, textile, building material,
cultivation, food and beverage, plastic foam, printing, dyeing and
washing, rubber processing, paper products,wood processing, hotel,
clothing and leather manufacturer etc.
Boiler technical parameter
| Boiler Model | DZL10.5-1.0/115/70-AII |
| Rated capacity(t/h) | 10.5 |
| Rated pressure(MPa) | 1 |
| Feed water temperature(℃) | 115 |
| Steam temperature(℃) | 70 |
| Active grate area(㎡) | 18 |
| Exhaust gas temp.(℃) | 146 |
| Design efficiency(%) | 81 |
| Fuel consumption(Kg/h) | 1587 |
| Main part weight(Ton) | 55.6 |
| Main part dimensions(mm) | 7650×3350×3500 |
| Delivery Mode | Assembled |
Advantages design of DZL model coal boiler
1. Coal/biomass boiler is durable and Long life time (more than
10years).
2. Enough steam output, less heat dissipation, high thermal
efficiency.lowest fuel consumption.
3. Lower power consumption.with high efficiency dust collector,
more Eco-friendly.
4. Full automatic control, Protection devices for overheating,
overpressure, lacking water, leak detection, flameout
5. The featured structure of the boiler: Threaded pipe, Airfoil
flue , Convex tube plate , The backwater towards hightemperature
tube plate, Simple loop circuit, Dust separated chamber, big
furnace, compact structure so on.
